Paper Sheet Labeling Machine

Paper Sheet Labeling Machine Specification

Frame Type
Heavy Duty SS Frame

Voltage
220-380 V

Motor Power
0.75 kW Servo Motor

Cooling System
Air cooled

Production Capacity
6000 pcs/hour

Power Rating
Single Phase or Three Phase

Machine Type
Fully Automatic

Control System
PLC Controlled

WorkingSpeed
Variable, up to 100 sheets/min

Drive
Servo Drive

Frequency
50/60 Hz

Accuracy
High precision labeling, 0.5 mm

Features
Touch screen panel, automatic feeding, emergency stop

Noise Level
<75 dB

Operating Temperature
5C to 45C

Model No
PSLM-6000

Connectivity Options
USB, Ethernet (optional)

Lubricating System
Automatic

Product Type
Paper Sheet Labeling Machine

Technology
Automatic labeling

Power Source
Electric

Operating Type
Automatic

Power
1.5 kW

Pressure
Standard atmospheric

Surface Treatment
Powder Coated

Dimension (L*W*H)
2300 x 1200 x 1500 mm

Weight (kg)
Approx. 450 kg

Color
Grey & Blue

Usage & Applications
Labeling paper sheets in packaging, printing industries

Conveyor Speed
Adjustable

Safety System
Emergency Stop, Overload Protection

Maximum Sheet Size
450 x 600 mm

Feeding System
Automatic Sheet Feeder

Material Used
SS304 for contact parts

Memory Storage
Program Save Function

Air Pressure Requirement
0.4-0.6 MPa

Sensors
Photoelectric Label Sensor

Changeover Time
Quick Changeover (<10 min)

Minimum Sheet Size
40 x 60 mm

Label Roll Diameter
Max. 300 mm

Display Type
Digital Touch Panel

Label Width Range
20 mm to 150 mm

Label Length Range
15 mm to 200 mm

About Paper Sheet Labeling Machine

Discover our Exceptional Paper Sheet Labeling MachineModel PSLM-6000, designed for excellent performance and high precision labeling. Now running a special Promotion: Try Now and boost your productivity with automatic feeding, a digital touch panel, emergency stop, and overload protection. Its automatic sheet feeder and quick changeover mechanism guarantee seamless operation. Gorgeous with a Grey & Blue powder-coated finish, this machine is built with heavy-duty SS304 contact parts. Save time and increase outputlabel up to 6000 pcs/hour with accuracy up to 0.5 mm. Perfect for packaging and printing industries in India.

Efficient Direction of Use & Material Features

To operate the Paper Sheet Labeling Machine, simply load your paper sheets onto the automatic feeder and select your preferred program via the intuitive digital touch panel. Crafted with sturdy SS304 for all contact parts, the machine ensures hygienic and long-lasting performance. With high-precision, automatic labeling and minimal manual intervention, it delivers uniform application on a wide range of sheet sizes, making it ideal for busy packaging or print production environments.

Certifications, Samples and Shipping Details

Our Paper Sheet Labeling Machine meets stringent quality certifications and can be dispatched swiftly once your order is placed. Sample demonstrations are available upon request to ensure your requirements are met. Shipped from major FOB ports across India, we offer flexible transportation and freight solutionsincluding secure packaging and trackingto guarantee safe delivery to your location. Experience reliability and transparency from order to installation.

FAQs of Paper Sheet Labeling Machine:

Q: How does the Paper Sheet Labeling Machine improve efficiency in production lines?

A: The machine features an automatic feeder and fast changeover capability, allowing high-speed labelingup to 100 sheets per minutesignificantly reducing downtime and manual labor in production.

Q: What safety features are included in the Paper Sheet Labeling Machine?

A: Equipped with emergency stop and overload protection, the machine ensures operator safety and equipment integrity during continuous operation.

Q: Where can the Paper Sheet Labeling Machine be used effectively?

A: Ideal for packaging and printing industries, this machine labels a range of paper sheet sizes, making it suitable for various commercial labeling tasks.

Q: What is the process for changing label sizes or formats?

A: The quick changeover system allows users to switch between label sizes and formats in under 10 minutes, minimizing interruptions and maximizing workflow.

Q: What is the benefit of the program save function?

A: The program save function enables you to store labeling configurations for repeated tasks, making future operations faster, consistent, and highly convenient.
