Horizontal Labeling Machine

Horizontal Labeling Machine Specification

Cooling System
Air Cooling

Accuracy
1 mm

Noise Level
70 dB

Machine Type
Horizontal Labeling

Connectivity Options
Touch Screen HMI, Sensor Integration

Control System
PLC Controlled

Plastic Processed
PET, HDPE Bottles

Model No
HLM-200

Power Rating
1.2 kW

Frame Type
Rigid Base Frame

Drive
Servo/Stepper Motor

Lubricating System
Automatic Lubrication

Operating Temperature
5C - 40C

Voltage
220V / 50Hz

Motor Power
0.75 kW

Production Capacity
100 - 300 bottles/min

Frequency
50 Hz

Features
High Precision Labeling, Easy Changeover, Low Maintenance

Product Type
Horizontal Labeling Machine

Technology
Automatic Labeling

Power Source
Electric

Operating Type
Automatic

Power
1.2 kW

Pressure
0.4 - 0.6 MPa

Surface Treatment
Stainless Steel Body

Dimension (L*W*H)
2000 x 900 x 1450 mm

Weight (kg)
330 kg

Color
Silver / White

Usage & Applications
Pharmaceutical, Food, Cosmetics, Chemical Industries

Max Label Roll Diameter
300 mm

Labeling Direction
Left to Right

Label Material Compatibility
Paper, PP, PET, PVC Labels

HMI Interface
7 Inch Touch Panel

Label Roll Inner Diameter
76 mm

Label Length
20-200 mm

Sensor Type
Fiber Optic / Photoelectric Sensor

Label Height
10-100 mm

Bottle Diameter Range
15-90 mm

About Horizontal Labeling Machine

Introducing the new release HLM-200 Horizontal Labeling Machinea laureate solution crafted for unbeatable performance in pharmaceutical, food, cosmetics, and chemical industries. Featuring a towering production capacity of 100300 bottles/min, this automatic machine boasts a 7-inch HMI touch panel, PLC control, and high-precision labeling (1 mm accuracy). Its robust stainless steel body, servo/stepper motor drive, and advanced sensor integration ensure low maintenance and longevity. Procure this limited-time offering from Indias trusted manufacturer and supplier for unrivaled efficiency and quality labeling.

Key Advantages and Distinctive Features

The HLM-200 Horizontal Labeling Machine stands out with its high accuracy, easy changeover, and automatic lubrication system. Widely used by esteemed pharmaceutical, food, chemical, and cosmetics manufacturers, its rigid base frame and precise fiber optic/photoelectric sensors deliver consistent results. The user-friendly HMI interface ensures swift operation, while the robust stainless steel body guarantees durability. This limited-time machine is designed for productivity and reliability, streamlining labeling processes effortlessly with low noise levels and minimal maintenance needs.

Global Export Markets and Swift Procurement

The HLM-200 Horizontal Labeling Machine is exported to major markets across Asia, Africa, Europe, and the Middle East. List price options are available for bulk procurement. Express shipping and dependable goods transport services ensure rapid deliverytypically within 24 weeks from order confirmation. Flexible payment terms are offered, including advance payments and letters of credit, making it easy for international clients to procure this machine and integrate it into their operations swiftly.

FAQs of Horizontal Labeling Machine:

Q: How does the HLM-200 ensure high labeling accuracy on various bottle sizes?

A: The HLM-200 uses advanced fiber optic or photoelectric sensors and a servo/stepper motor drive to maintain precise label placement with an accuracy of 1 mm, accommodating bottle diameters from 15 mm to 90 mm.

Q: What unique benefits does the HLM-200 offer over traditional labeling machines?

A: Unlike conventional models, the HLM-200 features an automatic lubrication system, seamless tool-free changeovers, and a stainless steel frame, ensuring low maintenance and extended machine life while handling a wide range of label materials.

Q: When is the ideal time to procure the HLM-200?

A: Take advantage of this limited-time offer for the new release HLM-200, as early procurement guarantees faster integration, potential discounts, and ensures access to the latest technology before stocks run out.

Q: Where can the HLM-200 Horizontal Labeling Machine be installed?

A: The machine is suitable for installation in various industrial settingsparticularly in pharmaceutical, food, cosmetics, and chemical production linesdue to its robust design and adaptable frame.

Q: What is the process for switching between different bottle or label sizes?

A: Switching between sizes is simplified with the easy changeover feature, allowing operators to adjust settings swiftly through the 7-inch touchscreen HMI, ensuring minimal production downtime.

Q: How does the export and delivery process work for international orders?

A: International customers benefit from express shipping and efficient goods transport arrangements, with dispatch typically occurring within 24 weeks. Flexible payment options and support with logistics are also provided to streamline import procedures.
